Antennas



Exemys offers a complete line of antennas of different frequencies, powers
and formats.


• 2.4 GHz and Wi-Fi
• 900 MHz
• GSM 850/900/1800/1900

2.4 GHz and Wi-Fi
OmnidirecTional
ORDERING CODE gAIN polarizaTION horizontal ANGLE vertical ANGLE
NDC04C24CN 8 dBi Vertical 360° 18.2°
NDC08C24CN 12 dBi Vertical 360° 7.2°
NDC16C24CN 15 dBi Vertical 360° 3.6°
yagis
ORDERING CODE elements gaIN polarizaTION horizontal ANGLE vertical ANGLE
NYS03C24ER 3 8.5 dBi Vertical 85° 69°
NYS07C24ER 7 12 dBi Vertical 75° 35°
NYS14C24ER 14 15 dBi Vertical 57° 23°
parABOLIC
ORDERING CODE gaIN polarizaTION horizontal ANGLE vertical ANGLE
NPR06C24EH 21 dBi V/H 18.1° 18.1°
NPR07C24ET 23 dBi Vertical 14.5° 14.5°
NPR08C24EH 24 dBi V/H 12.8° 12.8°
NPR10C24EH 27 dBi V/H 9.1° 9.1°
NPR15C24EH 30 dBi V/H 6.4° 6.4°
sector PANELS
ORDERING CODE gaIN polarizaTION horizontal ANGLE vertical ANGLE
Simples
NPA01C24SI 6.5 dBi Vertical 120° 77°
NPA12C24NH 12 dBi Vertical 120° 21.7°
NPA14C24NH 14 dBi Vertical 90° 18.2°
NPA17C24NH 17 dBi Vertical 90° 9.1°

Con reflector
NPA12C24NR 12 dBi Vertical 120° 21.7°
NPA14C24NR 14 dBi Vertical 90° 18.2°
NPA17C24NR 17 dBi Vertical 90° 9.1°
NPA19C24NR 19 dBi Vertical 60° 8.7°
indoor DOMES
ORDERING CODE gaIN polarizaTION AZIMUTH ELEVATION
NPI01C24 4 dBic Circular 150° 150°
NPI02C24 2x4 dBic Circular 150° 150°





900 MHz
OmnidirecTional
ORDERING CODE gaIN polarizaTION horizontal ANGLE vertical ANGLE
NDC02B89CN 2.15 dBi Vertical 360° 75°
NDC04B89CN 8.5 dBi Vertical 360° 24°
yagis
ORDERING CODE elements gaIN polarizaTIONn horizontal ANGLE vertical ANGLE
NYS03B89CE 3 8 dBi V/H 65° 90°
NYS05B89CE 5 9.5 dBi V/H 57° 85°
NYS07B89CE 7 12 dBi V/H 57° 45°
NYS10B89CE 10 13 dBi V/H 51° 50°
NYS14B89CE 14 15 dBi V/H 45° 35°
parABOLIC
ORDERING CODE gaIN polarizaTION horizontal ANGLE vertical ANGLE
NPR08B89ET 15 dBi V/H 29° 32°
NPR10B89ET 17 dBi V/H 25° 25°
NPR15B89ET 20.8 dBi V/H 16° 16°





GSM 850/900/1800/1900
OmnidirecTIONAL
ORDERING CODE band gaIN polarizaTION horizontal ANGLE vertical ANGLE
COD0511 GSM 850 4.5 dBi Vertical 360° 24°
COD0512 GSM 900 4.5 dBi Vertical 360° 24°
COD0901 GSM 850 5.15 dBi Vertical 360° 36°
COD0902 GSM 900 5.15 dBi Vertical 360° 36°
COD0896 GSM 1800 11 dBi Vertical 360° 34°
COD0897 GSM 1900 11 dBi Vertical 360° 34°
yagis
ORDERING CODE band elements gaIN polari-zaTION horizontal ANGLE vertical ANGLE
COD3232 GSM 850 3 8.15 dBi Vertical 60° 100°
COD3234 GSM 900 3 8.15 dBi Vertical 60° 100°
COD3262 GSM 850 6 10.2 dBi Vertical 40° 45°
COD3264 GSM 900 6 10.2 dBi Vertical 40° 45°
COD3292 GSM 850 9 12.5 dBi Vertical 35° 40°
COD3294 GSM 900 9 12.5 dBi Vertical 35° 40°
COD3293 GSM 1800 9 11 dBi Vertical
COD3297 GSM 1800 11 13.5 dBi Vertical 40° 40°
COD3295 GSM 1800 15 17 dBi Vertical 28° 27°
COD3291 GSM 1900 9 11 dBi Vertical
COD3296 GSM 1900 12 14 dBi Vertical
COD3299 GSM 1900 15 17 dBi Vertical







Documentation

Antennas Datasheet
